Equipment parameters
| Project | Parameter |
| Laser | 15W/20W JPT UV Glass Sanding Large Size Customization |
| work area | 800*800mm/1300*2500mm/1500*3000mm/2400*3600mm |
| scanning speed | 12000mm/s |
| wavelength | 655nm |
| First line width | 0.012mm |
| Minimum character | 0.15mm |
| Repeatability | ±0.03mm |
| Movement System | 5-axis linkage |
| Electrical system | Schneider, France |
| Voltage | 220V/380V |
| Control card | LIKE LASER German Customization |
| Refrigeration Method | Water-Cooling |
| Weight | 1200kg |
| Picture Format | BMP,PLT,AI,DXF,DST etc.Vector format |
DESCRIPTION
Large size glass laser engraving machine is a device specifically designed for high-precision marking and engraving on large size glass. It uses laser technology to perform non-contact processing on the glass surface through a laser beam, thereby achieving frosted carving on the glass surface
Working Principle
The large-sized glass laser engraving machine uses a laser beam to mark the surface of the glass. The high energy density of a laser beam can heat and evaporate glass materials, or alter the chemical properties of the glass surface, thereby forming fine markings, patterns, or text on the glass
Automation Control System
Automation control system: The large-sized glass laser marking machine is equipped with an advanced automation control system. Users can input the desired patterns, text, or designs through computer software, and set marking parameters such as depth, speed, and power through the interface.
High Precision and Speed
The large-sized glass laser marking machine has the characteristics of high precision and fast marking. It can achieve detailed and precise marking effects, and can complete the marking task of large-sized glass in a relatively short time.
